DRS-600 UB

DRS-600 UB

Product Image

Product Image

Features
Specifications

1 Mic / 1 AUX Input
MP3 Digital Player with USB, SD & Bluetooth Input
Pre Amplifier for recording programs
Line Input for connecting the output from any external PA Mixer Amplifier
Resettable circuit breaker for protection against overload and short circuit protection
Box Speaker/Driver Unit Selector Switch
Provided with Fan to Air Cool Circuit
AIJX-I is directly controlled by master

Power Output: 750 RMS at 30% THD (Rated) 600 RMS at 20% THD (Rated) 500 RMS at 10% THD (Rated)
Output Regulation: ≤ 2 dB no load to full load at 1kHZ
Input Channels: 1 x Mic. 0.65 mV/4.7 kΩ (Mic source impedance 50 Ω to 1 kΩ) 1 x Aux. 100mV/50 kΩ Line Input 1 V/ 50 kΩ
Frequency Response: 50 - 15000 Hz ± 3dB
S/N ratio: S/N ratio
Tone control Switch at Box Speaker Position Switch at Driver Unit Position: Bass:±10dB at 100Hz Treble:±10dB at 10KHz Bass:-10dB at 100Hz Treble:±10dB at 10KHz
Pre-amp Output: 200 mV /600Ω
Line Output 1: 1 V /1 kΩ
Output Taps for Speaker Matching: 4 & 8Ω (for direct connections) 70 & 100 V Line (for use with LMT)
Power Supply: AC 220-240V, 50/60Hz
Protection: AC Fuse 8 Amp. (T 8 A L); DC: 20 Amp. Circuit Protector
AC Power Consumption: 1000VA
DC Power Consumption: 8A
Dimension (W x D x H): 485 x 480 x 155
Weight: 23.900 Kg
